AlOx – PET Film
VisClear-AlOx: Aluminium Oxide metallized PET film with high barrier and superior metal adhesion for food packaging applications.
Application
- High barrier application: fresh/dried meat, candy/granola bars, dried fruit, snacks & biscuits
- Food packaging, hot fill, sterilization, pasteurization and retort application (110 °C – 135 °C)
Highlights
- High transparency & product visibility
- Superior surface energy for printing
- Excellent barrier performance (WVTR & OTR)
- Complies for food contact
- Pasteurizable, sterilizable, steamable
Technical Details
| Testing Methods & Properties | VisClear-AlOx-020 | VisClear-AlOx-010 | VisClear-AlOx-T | VisClear-AlOx-TZ | |
|---|---|---|---|---|---|
| Standards | Typical Values | ||||
| Thickness | GB/T 6672-2001 | 10 – 50 µm | |||
| Density | GB/T 1033.1-2008 | 1.4 g/cm³ | |||
| Tensile strength MD/TD | ASTM D882 | > 170 MPa | |||
| Elongation at break MD/TD | |||||
| Surface tension PET / AlOx side | GB/T 14216-2008 mN/m | > 52 / > 46 | > 52 / > 46 | > 45 / > 42 | > 45 / > 42 |
| OTR 50% HR, 23°C | ASTM D-3985 cm³/m².day | ≤1.5 | ≤1.0 | < 0.5 | < 0.5 |
| WVTR 90% HR, 38 °C | ASTM F-1249 g/m².day | ≤1.5 | ≤1.0 | <1.0* | <1.0 |
| Uniformity | ASTM D-1003 % | < 5 | |||
| Light transmitance | ASTM D-1003 % | > 88 | |||
| Surface adhesion | QB/T 2358-19983 N/15 mm | VisClear-AlOx-020: Normal AlOx Metallized Film, PET-AlOx-010: High Barrier AlOx Metallized Film, VisClear-AlOx-T: Protective coating AlOx Metallized Film, VisClear-AlOx-TZ: Steamable AlOx Metallized Film. |
|||
DISCLAIMER: This leaflet is provided for informational purpose only and is not binding, nor can it constitute specifications to the buyer. The information contained in this document is based on numerous tests and trials we have carried out in our laboratories. Deviations from the results thus obtained can therefore be experienced depending on the actual conditions of use. This document does not provide any guarantee with regard to compliance of our product with the typical values indicated, nor does it provide any guarantee as the suitability of our products for any particular use.
